Applications | Industries |
Tools | Machine engineering |
Instruments | Hydraulics |
Moulds | Aviation and space travel |
Cutting tools | Semiconductor and electronics |
knives | Medical and pharmacie |
Roller bodies | Petrochemistry |
Automotive | |
Optical | |
Agricultural | |
Nautical |
Technical details | |
Layer thickness | Min. 12 µm |
Hardness | 8H (pencil hardness) |
Wear resistance | Medium |
Corrosion protection | Good – combined with high phosphor nickel |
Phosphorus level | 1-4% |
Magnetic | Yes |
Electrical resistance | 15-30 µΩcm |
Substrates | I.a. steel, cast iron, aluminium, copper, brass, bronze, inconel, monel |
Process temperature | 90 ºC |
Weight | Up to 1.000 kg |
