Applications and technical details MCP® Micro Chrome Plating

Applications and technical details MCP® Micro Chrome Plating

Applications Industries
Cutting tools Hydraulics
Piston rings Machine engineering
Piston rods Pharmaceutics
Instruments Aviation and space travel
Rollers Medical
Cilindrical mounting surfaces Automotive
Bearing surfaces Semi-conductor
Gears Plastic processing industry
Conductors Injection moulding
Moulds Textiles
Mixers Food
  Laboratory



Technical details
Layer thickness 1-10 µm
Hardness 800-1100 HV
Wear resistance Excellent
Corrosion protection Good – as duplex very good
Friction coefficent Chrome on steel 0,16
Tensile strength 98 -390 Mpa
Magnetic No
Compressive stress 0
Tensile stress More than 1100 N/mm2
Substrates I.a. steel, cast iron, aluminium, copper, brass, bronze, inconel, monel
Process temperature Up to 60 ºC
Special norms I.a. AMS 2406 – QQC-320
Weight Up to 5.000 kg
