Blackprotect® black nickel

CZL Tilburg has succeeded to develop a perfect black coating which is 100 % free from Chromium (VI), Lead and Cadmium. This innovative black nickel process meets EU-directive RoHS. The black nickel phosphorous layer can be applied in optical instruments, as light absorbing material and for decorative purposes. The process is also applicable in aviation and aerospace applications.

For more information, please contact our experts:
phone +31 (0)13-5703370 or This email address is being protected from spambots. You need JavaScript enabled to view it. .

Warning: No images in specified directory. Please check the directoy!

Debug: specified directory - https://www.czltilburg.nl/images/processen/blackprotect

Technical specifications

Applications
Equipement
Instruments
Moulds
Punches
Cutting tools
Knives
Rollers
  Industries
Machine engineering
Hydraulics
Aviation and space travel
Semicondutor
Medical and Pharmacy
Petrochemistry
Automotive
Optical
Agriculture
Nautical
Thickness : > 12 µm
Hardness : 8H
Wear resistance : (low) Average
Corrosion protection : Good - in combination with high phosphorous nickel
Phosphorous content : 1-4 Weight%
Magnetic : Yes
Electric resistance : 15-30 µΩcm
Substrates : Steel, cast iron, aluminum, copper, brass, bronze, inconell, monel
Process temperature : 90 ºC
Specifications : -
Weight : up to 1.000 kg
Remarks : The layer is RoHS ELV compatible and UV-stable. The black colour gives a low light reflection in wave lenght ranging from 200nm till 900nm (measurement rapport is available).

The layer cannot withstand ultrasonic cleaning.

The layer may not be heated above 150°C.
